Inputs: 2 combo XLR-1/4″ microphone/line inputs 1 switchable Hi-Z instrument input Outputs: 2 balanced 1/4″ TRS 1 1/4″ headphone output Phantom Power (+48V): Yes USB: 2.0, bus powered Front Panel Controls: channel input gain, peak LED, phantom power, input monitoring, headphone and master volume Compatibility: – Windows 7, 8.1, 10 (ASIO 2.0, MMe, WDM, DirectSound) – Mac OS X 10.7 (and above) via CoreAudio (no driver install required) A/D/A Conversion: 24bit / 96kHz (max) ADC Dynamic Range: 102dBA@48kHz, SNR = 102dBA 48kHz DAC Dynamic Range: 108dBA48kHz, SNR = 108dBA @48kHz Inputs: 2 combo XLR- 1/4″ microphone/line inputs 1 switchable Hi-Z instrument input Outputs: 2 balanced 1/4″ TRS 1 1/4″ headphone output Phantom Power (+48V): Yes USB: 2.0, bus powered Front Panel Controls: channel input gain, peak LED, phantom power, input monitoring, headphone and master volume Compatibility: – Windows 7, 8.1, 10 (ASIO 2.0, MMe, WDM, DirectSound) – Mac OS X 10.7 (and above) via CoreAudio (no driver install required) A/D/A Conversion: 24bit / 96kHz (max) ADC Dynamic Range: 102dBA@48kHz, SNR = 102dBA 48kHz DAC Dynamic Range: 108dBA48kHz, SNR = 108dBA @48kHz
